Focal ES165KX2

TWO-WAY COMPONENT KIT 6½”

The ES 165 KX2 component kit is composed of two 165 mm (6½”) woofers with Kevlar® cones providing an extremely rich and punchy sound. The centre of the cone is equipped with a phase plug for improved sound dispersion around the vehicle.

The two “M”-shaped aramid-fibre TKMX inverted dome tweeters are equipped with bi-amplified crossovers. This enables perfect control over the high end for providing very smooth treble with perfect definition.

Thanks to its excellent power handling, this kit is the reference product of the K2 Power range. It even won over the hearts of the experts when it was officially revealed at the CES in Las Vegas, and received the CES Innovation 2016 award.

The kit is supplied with aluminium and mesh grilles.

EXCEPTIONAL SOUND FOR YOUR VEHICLE

The speaker drivers used for the K2 Power have been completely redesigned.Each component is the result of extensive research in acoustics to push back the limits of performance, of power and of precision!

KEVLAR® CONE Precision and dynamics

The K2 Power Kevlar® cone, a product of unique expertise Made In Focal, is to this day second to none. Composed of an ultra-light foam structure sandwiched between a thin layer of Kevlar® aramid fibres, and a layer of glass fibres, the K2 Power cone combines three key factors of quality acoustics: Rigidity / Lightness / Damping, for precise and dynamic sound.

NEW “M”-SHAPED TWEETER For a precise and smooth high end

The new K2 Power TKMX tweeter features an exclusive “M”-shaped structure. This new-generation aramid-fibre inverted dome tweeter provides great precision in the very high end, and its combination with a “push-pull” motor with IAL2 technology extends the low end of the frequency response and provides extraordinary harmonic balance.

2-way component kit
Diameter: 6½" (165mm)
Voice coil diameter: 19/1" (40mm)
Voice coil height: 02/3" (16.5mm)
Motor: Magnet
Tweeter: TKMX ("M" profile aramid fiber
inverted dome)
Cone: Composite K2 Power "W" sandwich cone
Surround: Tuned Mass Damper (TMD®)
Separated crossover: 6-12/12-18dB (3kHz)
Tweeter Adjustable level: +3; 0; -3dB/oct
Max. power: 240W
Nom. power: 120W RMS
Sensitivity (2.83V/1m): 92.5dB
Frequency response: 55Hz- 22kHz
Impedance: 2 Ω
Accessories: Supplied grilles
