MTX TX480D

The MTX Audio TX Series is a premium range of amplifiers designed in the USA and made with high quality MOSFET technology, with high output and fantastic sound quality at a great price you can't beat the TX range for the best of car audio technology.

The TX480D is well under-rated, these amplifiers produce over 110W RMS @4Ω <1%THD.

Also available, matching TX monoblock amplifiers; strappable 500W RMS TX6500D and 1000W RMS TX81000D.

Features :

Highly efficient HD Class-D wide range amp for speakers and subwoofers
Very compact size for an easy installation
2Ω stereo and 4Ω bridged compatible
Top quality components; Elna (DE) caps, IRF (USA) Mosfets
12dB/Oct flexible x-over
Impressive sound quality and dynamic
Full aluminium construction
Thermo regulated fan connector (for one or two external fans)

Specifications :

Class-D 4-channel amplifier
CTA2006 certified power- 4x 80 watts RMS @ 4Ω THD+N ≤1% (110W RMS+ in our testing with SMD and AP)- 4x 120 watts RMS @ 2Ω THD+N ≤1%- 2x 240 watts RMS bridged @ 4Ω THD+N ≤1%
Active x-over- High-pass (HPF) 12dB/Oct variable from 40Hz to 400Hz- Low-pass (LPF) 12dB/Oct variable from 40Hz to 400Hz
Signal/Noise ratio (1 watt) : >80dB
THD+Noise (Distortion) (1 watt) : ≤1%
Frequency response (±1dB) : 20Hz-30000Hz
Input sensitivity RCA : 200mV to 6V
Dimensions : 125mm x 215mm x 50mm
High and low level inputs
